COD: 098M040K
Categoria: Piedini
Caratteristiche Comuni alle Varianti
PFA_Color: Black
PFA_Model: Plastic PA. without bolt-down holes
PFA_Pack_Quantity: 10 pieces
PFA_Specials: ESD electrostatical discharging. other sizes. other colors. glued anti-slip plate on request. - As factory assembled leveling foot on request
PFA_Tip: Compatible Threaded Rod see 098MM05020M et sq.. - Compatible Nut see 4DIN439BM5M et sq. und 4DIN934M5M et sq.. - Compatible Anti-Slip Plate see 098MG020 et sq.
PA_upper_F_mm: 17.5
Caratteristiche Prodotto
| Produttore | FATH |
|---|---|
| Descrizione | Base PA for Swivel Feet. Ball Joint 10, Plastic PA. without bolt-down holes |
| Part number | 098M040K |
| Materiale | Plastic PA. glass ball reinforced |
| Set | Plastic PA. glass ball reinforced |
| Note | Black |
Caratteristiche specifiche varianti
| PA_Part_No | PA_Base | PA_upper_D_mm | PA_Weight_g | PA_Fmax_N | PA_Version |
|---|---|---|---|---|---|
| 098M020K | 20 | 19 | 2.0 | 980 | without anti-slip plate |
| 098M025K | 25 | 24 | 3.0 | 1960 | without anti-slip plate |
| 098M030K | 30 | 29 | 4.5 | 3430 | without anti-slip plate |
| 098M040K | 40 | 39 | 8.0 | 4900 | without anti-slip plate |
| 098M020KG | 20 | 19 | 3.0 | 980 | with Anti-slip plate |
| 098M025KG | 25 | 24 | 4.5 | 1960 | with Anti-slip plate |
| 098M030KG | 30 | 29 | 6.5 | 3430 | with Anti-slip plate |
| 098M040KG | 40 | 39 | 11.0 | 4900 | with Anti-slip plate |
